YJJ MH-411D Infrared Carbon Dioxide Gas Sensor CO2 Concentration Detection Sensor Probe

Product Description:

YJJ MH-411D Infrared Carbon Dioxide Gas Sensor CO2 Concentration Detection Sensor Probe

Features:

MH-411D carbon dioxide gas sensor is a universal and intelligent infrared gas sensor (hereinafter referred to as the sensor). This sensor uses the non-dispersive infrared (NDIR) principle to detect the C02 present in the air. The sensor is oxygen-independent, has stable performance and a long lifespan. It is equipped with internal temperature compensation. This sensor is a small-sized high-performance sensor made by closely integrating mature infrared absorption gas detection technology with micro-machining and excellent circuit design.

Application fields

Indoor air quality monitoring

HVAC and refrigeration

Industrial process and safety protection monitoring, agricultural and livestock production process monitoring

Gas detection: Carbon Dioxide

Operating voltage: 3.6~5VDC (requires safety barrier power supply)

Average current: < 85 mA

Measurement range: Selectable within 0~10% Vol range

Interface level: 3.0V

Output signal: UART 0.4-2V

Preheating time: 3 min

Response time: To < 30 S

Operating temperature: -20~60 ℃

Operating humidity: 0~95%RH (no condensation)

Dimensions: 20 mm x 22.2 mm

Weight: 35 g

Life span: 5 years

Protection level: IP54

Specifications:
